Discrete 8-Position Relay Rack EOL

$79.00

In Stock:

PB8HS

Accepts 12-22 gage insulated wire with stripped ends
Designed for panel mounting with four stand-offs
Logic side connection is via 50-pin header
Each power side point is individually isolated
Supports up to eight I/O modules
Compatible with modules from WRC (WRC4), Opto 22 (G4), Grayhill (G5), and Crydom (C4)
Power-side terminals are polarized for DC applications and non-polarized for AC applications
Signal side has a common DC return and common logic supply bus (+Vcc) for negative-true logic applications

Have a Question?
1-864-843-4343
Chat
Email

Print Page

Product Details

The PB8HS relay rack can be used with up to eight discrete I/O modules, including input modules, output relays, override relays, watchdog timers, and mechanical relays. On the signal side, it features a 50-pin header connector for easy interface via standard IDC ribbon cables. Terminal blocks accept insulated wire with stripped ends. Each power side point is individually isolated from each other.\n\nCompatible with modules from Western Reserve (WRC), Opto 22, Crydom, Gordos, and Grayhill.
