DIO-16.LPCIe: LP PCI 8 RR Output/8 Iso. Input DIO Adapter
8012E-ROHS
Call for price
8012-ROHS
Product Details
The 8012 Low Profile PCI digital interface provides eight Reed relay outputs (SPST) and eight optically isolated inputs. Reed relays are well suited for low current applications. The relays are normally open, and close when energized. The board is MD1 Low Profile and Universal Bus (3.3V and 5V) compatible.
The 8012 is for use in Low Profile PCI slots only. Order the 8012S if you have a standard size PCI slot. The inputs on the 8012 are rated for 3-13V. For 10-30V inputs, order the 8012H.
Sealevel’s SeaIO Classic software drivers and utilities make installation and operation easy using Microsoft Windows operating systems.
Get a jump start on your digital I/O development with The Digital I/O Handbook that will provide helpful information that you will use again and again. Check out Chapter 1 for an overview of logic principles.
Host Interface(s)
PCI (Low Profile)
Operating Temperature
0°C to 70°C (32°F to 158°F)
Power Requirement
+5V @ 280mA
Storage Temperature
-50°C to 105°C (-58°F to 221°F)
Humidity Range
10-90% Relative Humidity/Non-Condensing
